Fiche : [DATA454]
Titre : Power Management Guide 2011, Texas Instrument, http://power.ti.com , 2011.
Cité dans : [DIV095] Librairie TEXAS INSTRUMENTS - UNITRODE et Notes d'applications diverses, octobre 2013.
Auteur : Texas Instrument
Site : http://power.ti.com
Date : 2011
Lien : private/SLVT145K.pdf - 97 pages, Ko.
Pages : 1 - 97
Vers : Table of Contents
Portable and Line Power Solutions
Line Power Solutions . 3
Portable Power Solutions 3
Emerging Power Applications
Overview 4
Power for Smart Meters 4
LED Lighting 5
Wireless Power (bqTESLA) . 6
Energy Harvesting . 6
Solar Charging . 7
HEV Battery Management 8
High-PSRR Telecom 9
Point-of-Load Solutions
Overview 10
Integrated Power Solutions (with Built-in Inductor) . 11
Step-Down (Buck) Converters . 13
Step-Up (Boost) Converters 16
Buck-Boost Converters . 19
Linear and Low Dropout (LDO) Regulators . 20
Multi-Output Power Management Units . 24
DC/DC Controllers (External Switch) . 27
Charge Pumps . 30
Digital PWM Controllers and Drivers . 32
Non-Isolated Power Modules 35
NexFET™ Power MOSFETs . 38
Isolated Solutions
Overview 41
Power Factor Correction (PFC) . 42
PWM Power Supply Controllers 43
MOSFET Drivers 48
Digital PWM Controllers 50
Isolated Power Modules 51
LED Lighting
LED Driver Controllers . 52
LED Video Display Drivers . 54
Display Power
Overview 56
Display Bias, Level Shifters and Scan Drivers . . 56
LED Backlighting Drivers . 59
Battery Management Products
Overview 62
Charger Front-End Protection . 63
Battery Charge Management 63
Single-Cell Solutions – Battery Fuel Gauges 67
Single-Cell Solutions – Authentication for Batteries and Peripherals . 68
Multi-Cell Solutions – Battery Fuel Gauges . . 69
Multi-Cell Solutions – Lithium-Ion Protection 71
Power Protection and Control
Overview 72
Power-over-Ethernet . 72
Protection and Power Switches 74
Voltage Supervisors and Digital Sequencers 83
Special Applications
White LED Backlight, High-Current LED and Camera LED Flashlight Drivers 86
Resources
Design Support . 88
Packaging 90
Device Index 92
TI Worldwide Technical Support (back cover)
